MICROSOFT’S December 2016 PATCH RELEASES

MICROSOFT’S December 2016 PATCH RELEASES

by | Dec 14, 2016 | Deployment, Fixes, Patch Management, Patch Releases, Risk, SCCM, Security

MICROSOFT’S December 2016 PATCH RELEASES

patch tuesday aliens

Microsoft have released 12 new Patch Tuesday releases for deployment this month of December.

See how you can remove the risk of patch deployment by adding SnaPatch to your SCCM patching infrastructure?

MS16-144 – Critical

Cumulative Security Update for Internet Explorer (3204059)
This security update resolves vulnerabilities in Internet Explorer. The most severe of the vulnerabilities could allow remote code execution if a user views a specially crafted webpage using Internet Explorer. An attacker who successfully exploited the vulnerabilities could gain the same user rights as the current user. If the current user is logged on with administrative user rights, an attacker could take control of an affected system. An attacker could then install programs; view, change, or delete data; or create new accounts with full user rights.

MS16-145 – Critical

Cumulative Security Update for Microsoft Edge (3204062)
This security update resolves vulnerabilities in Microsoft Edge. The most severe of the vulnerabilities could allow remote code execution if a user views a specially crafted webpage using Microsoft Edge. An attacker who successfully exploited the vulnerabilities could gain the same user rights as the current user. Customers whose accounts are configured to have fewer user rights on the system could be less impacted than users with administrative user rights.

MS16-146 – Critical

Security Update for Microsoft Graphics Component (3204066)
This security update resolves vulnerabilities in Microsoft Windows. The most severe of the vulnerabilities could allow remote code execution if a user either visits a specially crafted website or opens a specially crafted document. Users whose accounts are configured to have fewer user rights on the system could be less impacted than users who operate with administrative user rights.

MS16-147 – Critical

Security Update for Microsoft Uniscribe (3204063)
This security update resolves a vulnerability in Windows Uniscribe. The vulnerability could allow remote code execution if a user visits a specially crafted website or opens a specially crafted document. Users whose accounts are configured to have fewer user rights on the system could be less impacted than users who operate with administrative user rights.

MS16-148 – Critical

Security Update for Microsoft Office (3204068)
This security update resolves vulnerabilities in Microsoft Office. The most severe of the vulnerabilities could allow remote code execution if a user opens a specially crafted Microsoft Office file. An attacker who successfully exploited the vulnerabilities could run arbitrary code in the context of the current user. Customers whose accounts are configured to have fewer user rights on the system could be less impacted than those who operate with administrative user rights.

MS16-149 – Important

Security Update for Microsoft Windows (3205655)
This security update resolves vulnerabilities in Microsoft Windows. The more severe of the vulnerabilities could allow elevation of privilege if a locally authenticated attacker runs a specially crafted application.

MS16-150 – Important

Security Update for Secure Kernel Mode (3205642)
This security update resolves a vulnerability in Microsoft Windows. The vulnerability could allow elevation of privilege if a locally-authenticated attacker runs a specially crafted application on a targeted system. An attacker who successfully exploited the vulnerability could violate virtual trust levels (VTL).

MS16-151 – Important

Security Update for Windows Kernel-Mode Drivers (3205651)
This security update resolves vulnerabilities in Microsoft Windows. The vulnerabilities could allow elevation of privilege if an attacker logs on to an affected system and runs a specially crafted application that could exploit the vulnerabilities and take control of an affected system.

MS16-152 – Important

Security Update for Windows Kernel (3199709)
This security update resolves a vulnerability in Microsoft Windows. The vulnerability could allow information disclosure when the Windows kernel improperly handles objects in memory.

MS16-153 – Important

Security Update for Common Log File System Driver (3207328)
This security update resolves a vulnerability in Microsoft Windows. The vulnerability could allow information disclosure when the Windows Common Log File System (CLFS) driver improperly handles objects in memory. In a local attack scenario, an attacker could exploit this vulnerability by running a specially crafted application to bypass security measures on the affected system allowing further exploitation.

MS16-154 – Critical

Security Update for Adobe Flash Player (3209498)
This security update resolves vulnerabilities in Adobe Flash Player when installed on all supported editions of Windows 8.1, Windows Server 2012, Windows Server 2012 R2, Windows RT 8.1, Windows 10, and Windows Server 2016.

MS16-155 – Important

Security Update for .NET Framework (3205640)
This security update resolves a vulnerability in Microsoft .NET 4.6.2 Framework’s Data Provider for SQL Server. A security vulnerability exists in Microsoft .NET Framework 4.6.2 that could allow an attacker to access information that is defended by the Always Encrypted feature.

Now that you have made it this far, a quick shameless plug for our software portfolio. 🙂

SnaPatch – Patch Management Addon for Microsoft’s SCCM.

SnapShot Master – Take control of your virtual machine snapshots, works with both Hyper-V and Vmware.

Azure Virtual Machine Scheduler – Save money and schedule the shutdown and power on of your virtual machines within Microsoft’s Azure Cloud.

Azure Virtual Machine Deployer – Deploy VMs to Microsoft’s Azure cloud easily, without the need for powershell.

Configuration Manager 1606 Hotfix KB3180992

Configuration Manager 1606 Hotfix KB3180992

by | Oct 23, 2016 | How To, Patch Releases, SCCM

Configuration Manager 1606 Hotfix KB3180992

If you’re using System Center Configuration Manager (SCCM) and haven’t updated to build 5.00.8412.1204 yet, it’s time to do so. Microsoft has released a hotfix KB3180992 to fix various issues with SCCM. In this article, we’ll guide you through the installation process and explain how to fix the known issues that this hotfix addresses.

What’s New in SCCM 1606 Hotfix KB3180992

This hotfix addresses several known issues with SCCM, including:

  • An exception error that occurs when selecting the “Update all clients in the hierarchy using production client” option on the Client Upgrade tab of Hierarchy Settings Properties.
  • Software update installation freezing on SCCM clients.
  • Inaccurate client counts on the Production and Preproduction Client Deployment dashboards.
  • Incorrectly showing a state of Compliant on the Device Compliance section of the Software Center application.
  • Incorrectly showing an error state that indicates the role is not available on the Service Connection Point after upgrading to version 1606.
  • The SMS Agent Host process consuming excessive CPU resources on Pull Distribution Points after updating to version 1606.
  • The ccmexec.exe process stopping responding when distributing a software update package containing many updates to a Pull Distribution Point.

SCCM 1606 Hotfix FAQ

Question Answer

What is System Centre Configuration Manager?

 System Centre Configuration Manager (SCCM) is a software management tool that allows administrators to manage large numbers of computers and devices from a single location.

What is Configuration Manager 1606 Hotfix KB3180992?

 Configuration Manager 1606 Hotfix KB3180992 is an update for SCCM that fixes various issues identified with SCCM, including a freeze during software update installation and inaccurate client counts.

How do I install Configuration Manager 1606 Hotfix KB3180992?

 To install this update, go to Administration, then expand Cloud Services and highlight Updates and Servicing. In the main console window, you should see the SCCM 1606 Hotfix has downloaded and is available for deployment. Highlight the update (KB3180992), right-click, then run the prerequisite pack. This will now check that your SCCM meets the prerequisites for this update. Once the prerequisite check has completed, highlight the update once again, right-click, and choose Install Update Pack.

What should I do if the Service Connection Point incorrectly shows an error state after upgrading to version 1606?

 If the Service Connection Point is already showing an error state after upgrading to version 1606, you need to change the Availability State registry value from 1 to 4 under HKEY_LOCAL_MACHINE-SOFTWARE-Microsoft-SMS-Operations Management-SMS Server Role-SMS Dmp Connector, then restart the SMS Executive service on the site server.

How do I validate the client update on my preproduction SCCM members?

 On the Client Update Options Tab of the Configuration Manager Updates Wizard, you have the chance to validate the client update on your preproduction SCCM members. Simply select the checkbox next to “Validate in pre-production collection” and choose the pre-production collection to use for validation.

How long does it take to install SCCM 1606 Update 1?

 Installation of SCCM 1606 Update 1 may take some time, as it installs in the background. Keep refreshing the window to see when KB3180992 shows a status of installed.

How to upgrade SCCM

To install this update, go to Administration, then expand Cloud Services and highlight Updates and Servicing.

SCCM 1606 Update 1

In the main console Window, you should now see the SCCM 1606 Hotfix has downloaded and is available for deployment.

SCCM 1606 Update 1 - 2

Highlight the update (KB3180992), Right Click then Run Prerequisite Pack. This will now check that your SCCM meets the prerequisites for this update.

SCCM 1606 Update 1 - 3

This may take some time, so be patient and be sure to refresh the console to make sure the prerequisite check has been successful.

SCCM 1606 Update 1 - 4

Now that the prerequisite check has completed, highlight the update once again, right click and choose Install Update Pack

SCCM 1606 Update 1 - 5

Next you are presented with the Configuration Manager Updates Wizard. Click on Next to start the installation.

SCCM 1606 Update 1 - 6

On the Client Update Options Tab, you have the chance to validate the client update on your preproduction SCCM members. In this example, I am upgrading without validation.

SCCM 1606 Update 1 - 7

Click Next to continue.

Accept the License Terms and click Next.

SCCM 1606 Update 1 - 8

Review you are happy with the options you have selected on the Summary Tab, then click Next.

SCCM 1606 Update 1 - 9

Installation of the SCCM 1606 Update 1 will now occur. If all goes well, you should see the Completion Window as below. SCCM will install this in the background, so it may take some time. Keep refreshing the Window, to see when KB3180992 shows a status of installed.

SCCM 1606 Update 1 - 10

Deploying a Zero Day Exploit Update Fix with Microsoft SCCM 2012

Deploying a Zero Day Exploit Update Fix with Microsoft SCCM 2012

by | Jul 5, 2016 | Deployment, How To, Patch Management, Patch Releases, Risk, SCCM, Security

Deploying a Zero Day Exploit Fix with Microsoft SCCM 2012

Zero Day exploits are vulnerabilities that are found and can be used by hackers to exploit and use for malicious or personal intent. These exploits have been known to affect both software and hardware, causing issues to programs, data, computers, and networks. Once a patch or fix is released by the vendor, the issue is no longer known as a Zero Day vulnerability. In this article, we will discuss how to remediate Zero Day attacks and how to deploy a Zero Day exploit fix using Microsoft SCCM

Remediating Zero Day Attacks

Unfortunately, there isn’t much that can be done until a fix or update is released that patches the security hole. Once a patch is released, it is best to deploy and apply the patch as soon as possible. To reduce the risk of unknown vulnerabilities, it is good practice to keep your hardware and software up to date. This will remove any previously found vulnerabilities from your environment as patches are applied. Having a patching process in place and suitable infrastructure to do so (e.g., Microsoft SCCM and SnaPatch) where you can deploy updates easily and often are also good practices.

Deploying a Zero Day Exploit Patch Using SCCM

Unfortunately, there isn’t much that can be done until a fix or update is released that patches the security hole. Once a patch is released, it is best to deploy and apply the patch as soon as possible. To reduce the risk of unknown vulnerabilities, it is good practice to keep your hardware and software up to date. This will remove any previously found vulnerabilities from your environment as patches are applied. Having a patching process in place and suitable infrastructure to do so (e.g., Microsoft SCCM and SnaPatch) where you can deploy updates easily and often are also good practices.

 Zero Day Exploit Overview

So what exactly is a Zero Day Exploit you ask? To be exact, a Zero Day Exploit is a vulnerability that is found that a possible Hacker can use to exploit and use for malicious or personal intent. The Vendor (software or hardware) has Zero Days to plan, mitigate and fix the issue so that there is no further exploitation of the vulnerability. The exploits have been known to be for either software (Operating Systems and Software) and hardware. They have been known to cause issues to programs, data, computers and to the network.

Zero Day Exploit

Zero Day Attack Timeline

In the case of a breach being found in some software, a Zero Day Exploit normally follows this;

  1. A hacker finds a vulnerability with a product (software/hardware).
  2. The hacker writes an exploit and uses it either to be malicious or financial gain.
  3. Exploit is detected either by Users, Security Companies or the Vendor themselves.
  4. The Vendor studies the new exploit and develops a fix.
  5. The Vendor releases a new patch to fix the exploit
  6. Users install the Patch or Virus Definition update.

The biggest issue with a Zero Day Exploit is that they are generally unknown until they have been used to breach systems, leaving everyone vulnerable until the Vendor releases security advice on how to remediate the issue or a patch or update. This could be days, weeks, months or even years before the Vendor learns of the vulnerability. Once a Patch or Fix has been released by the Vendor, then the issue is no longer known as a Zero Day Vulnerability.

How to remediate Zero Day Attacks

Unfortunately there isnt much that can be done until there is a fix or update released that patches the security hole. Once a patch is released it is best to deploy and apply the patch as soon as is possible.

To also reduce the risk, it is good practice which will aid you in mitigation of vulnerabilities that are unknown to yourself if you keep your hardware and software patched up to date. This will remove from your environment any previously found vulnerabilities as patches are applied. Having a Patching Process in place and suitable infrastructure to do so (ie Microsoft SCCM and SnaPatch for instance) where you can deploy updates easily and often are also good practice.



Using SCCM to deploy a Zero Day Exploit Patch

If you are using Microsofts SCCM 2012, you can easily deploy an update that addresses a Zero Day Vulnerability by following these steps;

  1. Log on to your SCCM console, then go to Software Library, then expand Software Updates and highlight All Software Upates. Now Right Click and choose Synchronise Software Updates. This will synchronise your SCCM server with your WSUS updates server. Allow a few minutes for the new updates to populate the view. You can check the Wsyncmgr.log to view the update synchronisation.Zero Day Exploit
  2. If you know the Bulletin ID number (the update number released by Microsoft in the format MSXX-XXX. In this example I am choosing MS16-082), you can now search for this within the console.SCCM Zero Day Exploit
  3. Make sure that the update has downloaded and if not, right click the update and choose Download. You will obviously need to give the update sometime to download in to your environment and be ready for deployment. Click this link to see how to manually download updates if you dont know how.

    Zero Day Exploit Download
  4. When the update is downloaded and ready for deployment, you are now ready to deploy the Update. (If you are using SnaPatch to deploy the updates, go straight to the SnaPatch Section below.)
    Right Click the update (or updates) and choose Deploy.
    Enter in a Deployment Name, a Description, and choose the collection you wish the Zero Day exploit to deploy to. Once you have chosen the correct settings, click on Next.SCCM Zero Day Exploit General Tab
  5. On the Deployment Tab, leave the type of deployment as Required and choose the level of detail you want then click on Next.SCCM Zero Day Exploit Deployment Settings
  6. Now to schedule when you want the update to deploy. As this is a Zero Day Exploit that you want patched quickly, schedule the patch to be available As Soon As Possible for both the Software Available Time and Installation Deadline. Please note, that more often than not, the installation of an update will cause systems to restart. Please make sure you have informed the appropriate people and that you have approval for deployment. Nothing worse than deploying an update and having to answer to Management as you caused unwarranted system outages.SCCM Zero Day Exploit Schedule Tab
  7. The User Experience Tab is where you set how the deployment will interact with Users. You can set if the users are notified within the Software Centre that an update is available for installation, when the deployment deadline is reached whether the update can install and restart the system outside a maintenance window, and finally whether you wish to suppress a system restart. As this is an urgent deployment, I have chosen to allow installation and restart to be allowed outside any maintenance windows. Choose the settings you require and click on Next.SCCM Zero Day Exploit User Experience Tab
  8. If you have System Centre Operations Manager (Microsoft SCOM) in your environment you can choose to generate an alert with criteria you specify. In this example we are not going to specify any settings. Click on Next when you have made your selections.SCCM Zero Day Exploit Attack
  9. The Download Settings tab allows you to choose client download settings. If a client is on a slow or unreliable network boundary you can choose if they dont install the update or from another distribution point. Allowing clients to share content between themselves is a great feature of SCCM as it will stop other client machines downloading the same updates and possibly flooding a network link. The clients will all share the update between themselves if they are on the same subnet. Also if they cannot download the update from a SCCM distribution point, allowing them to download from Microsoft Update is available as well.
    Click on Next when ready to.Zero Day Attack
  10. Now you can review all the settings on the Summary Tab. Confirm you are happy with all the settings and then click Next.Microsoft Zero Day Exploit
  11. The progress of the deployment will now be shown.Zero Day Exploit Progress
  12. Your Zero Day Exploit deployment should now be ready to be deployed to your SCCM clients as per the settings you have set.Microsoft Zero Day Exploit Deployment

Using SnaPatch for Zero Day Exploit Deployment

If you are using SnaPatch to aid you with the deployment of Windows Updates with Microsoft’s SCCM, you can follow on from Steps 1 to 4 from above.

  1. Open the SnaPatch console and choose the SnaPatch Icon to start the snapshot and patch deployment process.Zero Day Exploit SnaPatch
  2. Now you are presented with all the SCCM Collections and Systems available to deploy the Zero Day Exploit to. Choose the systems you want to receive the patch and click on Add.
    SnaPatch Zero Day Exploit
    If the machines are virtual (either a VMWare or HyperV virtual machine) you can choose whether to take a snapshot of the servers prior to deployment of the zero day patch. Should the servers not have a successfully snapshot completed, then they will not receive the update deployment. The snapshot of the virtual machines gives you a quick rollback position should the update cause an issue in your environment.
    When you have chosen all the machines you wish and if you would like a snapshot, click on the green arrow to continue.
  3. The next window in the SnaPatch process, is to chose the update you wish to deploy. As this is a Zero Day patch and we know the Microsoft article number (which in this example is MS16-082), type in the KB or MS article number and choose search.
    Select the update, confirm that it has been downloaded (as per step 3 above) and now choose if you want the update to deploy to an existing Update Group or to create a new one. SnaPatch deploy Zero Day Exploit
  4. As this is an urgent deployment, I am choosing Create & Deploy Update Group. Give the Software Update Group a Name and Description and click Create.SnaPatch Zero Day Exploit SCCM
  5. Confirmation that the Software Update Group has been created. Click OK.Zero Day Exploit Software Update Group
  6. Next we have to schedule deployment. Click Schedule Job.SnaPatch Zero Day Exploit Schedule
  7. Now on the scheduling window, click on New.SnaPatch Zero Day Exploit scheduling
  8. Choose an appropriate schedule when you would like the deployment to happen. This will set up the update deployment for the time you specify. Click OK when you are ready to proceed, then close the scheduling Window.SnaPatch SCCM Zero Day Exploit
  9. On the Maintenance Window choose the duration you want the snapshots to be performed and the updates to be installed during. Click on Finish when complete.Zero Day Exploit Maintenance WindowThats all there is to it. SnaPatch will now create a deployment of the Zero Day Exploit Patch within Microsoft SCCM and set the Maintenance Window. When the maintenance window is reached, SnaPatch will interact with your Vmware or HyperV hosts and start a snapshot of the servers you have selected. Once the snapshot is complete SnaPatch then contacts SCCM and allows SCCM to deploy the patch to those servers. You will also receive email notifications throughout the snapshot and deployment process.
    Click for further information on SnaPatch Patch Management.

Zero Day exploits can cause serious issues to programs, data, computers, and networks. It is essential to deploy patches and fixes as soon as possible to reduce the risk of exploitation. Using Microsoft SCCM 2012 to deploy a Zero Day exploit fix is an easy process that can be completed by following the steps outlined above. Keeping your hardware and software up to date and having a patching process in place are good practices to mitigate the risk of unknown vulnerabilities.

Create a SCCM Automatic Deployment Rule for SCEP definition updates

Create a SCCM Automatic Deployment Rule for SCEP definition updates

by | Jun 30, 2016 | Deployment, Endpoint Protection, How To, SCCM

SCEP Definition Automatic Deployment Rule in SCCM 2012 R2

If you have setup your SCCM environment with the Microsoft product, System Centre Endpoint Protection (SCEP) and have deployed the SCEP agent to your client computers the next task you need to complete is the creation of an Automatic Deployment Rule for the antivirus updates.  Automatic Deployment Rules as the name suggests, automate the deployment of updates and definitions to your environment. You can set deadlines when things should install, maintenance windows when reboots and installation should occur and also the download of Windows updates ( you can specify products you would like updates to download for and what severity ie critical, important and security) and SCEP definitions without any manual intervention.

Creating an Automatic Deployment Rule for System Centre Endpoint Protection (SCEP) definition updates in SCCM can help streamline the process of deploying and updating antivirus definitions across an organization. By automating the deployment of updates and definitions, IT administrators can save time and ensure that all client computers have the latest protection against known threats. With SCCM’s customization options, administrators can set deadlines for updates, specify maintenance windows, and even control the download of Windows updates. This ensures that updates are deployed efficiently and without any manual intervention, allowing administrators to focus on other important tasks.



Creating an Automatic Deployment Rule in SCCM 2012 R2 for SCEP Definition Deployment

Create Automatic Deployment Rule

Open your SCCM 2012 console and navigate to Software Library – Overview – Software Updates – Automatic Deployment Rules.

Right click Automatic Deployment Rules and then choose Create Automatic Deployment Rule

SCEP ADR Setup

SCEP ADR – General Tab

Now specify a descriptive name for the Automatic Deployment Rule, a description that will easily identify what this ADR is for and then choose an appropriate template from the dropdown box (I have chosen the standard definitions updates). Then Click on Next

SCEP Definition Updates

SCEP ADR – Deployment Settings Tab

I left the settings as default on this page as I want to automatically approve any license agreements and dont have a requirement to wake up client computers. If you want to deploy the SCEP updates after hours while your client computers are off and wish to wake them up for the client updates (this depends on if your environment has Wake On Lan capability) choose the Wake On Lan checkbox.

SCEP Automatic Deployment Rule

SCEP ADR – Software Updates Tab

Make sure that the search criteria is correct, that the Product says Forefront Endpoint Protection 2010 or Windows Defender and that the Update Classification shows Definition Updates and choose next.

SCEP Definition Automatic Deployment Rule

SCEP ADR – Evaluation Schedule Tab

Choose how often the Software Update Point synchronises.

SCEP Definition ADR

SCEP ADR – Deployment Schedule Tab

Now we can configure when the updates are available to be installed on client computers. In the example below, I left this as the default 1 Hour. You can choose what ever is suitable for your environment.

SCEP Updates

SCEP ADR – User Experience Tab

The following screen is where you set whether or not you will notify the users that there is a new SCEP definition update available for their machines. Most often than not, it is best to suppress these notifications from the end user as there could be multiple updates released daily. Notifying them every few hours would surely annoy them, which in turn they will annoy the Administrator.

SCEP Definition Deployment

SCEP ADR – Alerts Tab

If you have System Centre Operations Manager (Microsoft’s SCOM) you can choose whether any alerts are enabled / disabled and if required, what conditions to generate an alert

SCCM SCEP

SCEP ADR – Download Settings Tab

Now we are up to the Download Settings page. Choose the option that is suitable to your environment. It is always a good idea, if you have lots of remote sites without an SCCM distribution Point available, to allow the clients to share content with other clients on the same subnet.

SCCM SCEP Updates

SCEP ADR – Deployment Package Tab

On this page, we are creating a new deployment package for the Definitions Updates. Again, it is good practice to give a descriptive name and description that is easily identifiable to others. Also, choose a source location with enough storage to store the definitions.

System Centre Endpoint Protection

SCEP ADR – Distribution Points Tab

Choose which distribution points you would like the update definitions to be shared to and from. I choose the All Distribution Points as I want the updates available from everywhere in the environment.

SCCM System Centre Endpoint Protection

SCEP ADR – Download Location Tab

If you are downloading the definition updates manually, you can set the location for where SCCM should look for new definitions. If not, choose Download Software Updates from the Internet and click on Next.

SCCM Antivirus

SCEP ADR – Language Selection Tab

Specify which languages you wish the SCEP definition update to deploy as. You can choose multiple languages as required.

SCCM SCEP Antivirus

SCEP ADR – Summary Tab

Review the Summary page to confirm you are happy with the settings you have chosen. Once you are satisfied with your selection, click Next.

SCCM SCEP Antivirus updates

SCEP ADR – Progress Tab

The Automatic Deployment Rule will quickly run through some checks, and once completed, click on Close.

SCCM SCEP Antivirus definitions

SCEP ADR – Manual Invocation

That is all there is too it. The Automatic Deployment Rule will run with all the settings you have selected. If you ever wish to manually run the rule, right click it and choose run now.

SCCM SCEP Antivirus definition deployment

Click on the link to see how to create an SCCM Automatic Deployment Rule for Windows Updates.

SCCM ADR for SCEP Conclusion

Creating an Automatic Deployment Rule in SCCM 2012 R2 for SCEP Definition Deployment is a straightforward process that can save administrators valuable time. Once you set up the Automatic Deployment Rule, the updates will deploy to your client computers without any manual intervention.

Create a SCCM Automatic Deployment Rule

Create a SCCM Automatic Deployment Rule

by | Jun 28, 2016 | Deployment, How To, Patch Management, SCCM

SCCM Automatic Deployment Rule

As a system administrator, managing updates for your organization’s desktops, laptops, and servers can be a challenging task. It requires a lot of time and effort to keep your machines up-to-date with the latest software updates and security patches. However, with the SCCM Automatic Deployment Rule (ADR) feature, you can automate the entire update management process and save valuable time.

An Automatic Deployment Rule (ADR) is a useful feature for organizations using System Center Configuration Manager (SCCM) to manage their IT environment. With an ADR, administrators can automate the process of downloading, approving, and deploying software updates to client machines, saving time and effort compared to manually managing updates. Additionally, an ADR ensures that machines are up-to-date with the latest software updates and security patches, reducing the risk of security vulnerabilities and software bugs. By creating an ADR, administrators can specify what products and severity of updates they want to download, approve, and deploy, giving them greater control over the update management process. Overall, an ADR is an effective tool for streamlining the software update management process and maintaining a secure and up-to-date IT environment.

In this article, we’ll explore the SCCM Automatic Deployment Rule feature and show you how to create an ADR for your organization’s update management.

SCCM Automatic Deployment Rule FAQs

What is an ADR in SCCM?

An ADR is a feature of SCCM that automates the process of downloading, approving, and deploying updates to client machines.

How does an ADR work?

An ADR downloads the latest updates as per the requirements set by the administrator, distributes them to distribution points, and then deploys them to the target collection during the maintenance and deployment windows specified.

What are the benefits of using an ADR in SCCM?

The benefits of using an ADR include automating the update management process, saving time and effort for system administrators, ensuring machines are up-to-date with the latest software updates and security patches, and enabling control over what products and severity of updates to download, approve, and deploy.

How do I create an ADR in SCCM?

To create an ADR in SCCM, you need to open the SCCM console, navigate to the Software Library, expand Software Updates, and select Automatic Deployment Rules. From there, you can follow the steps to create an ADR, including selecting the products and classifications to include, configuring the deployment settings, and specifying the collection to which the updates will be deployed.

What are some best practices for using an ADR in SCCM?

Best practices for using an ADR in SCCM include following guidelines for patch management, creating a patch management process, setting maintenance and deployment windows, and monitoring Microsoft’s monthly patch releases.

Can an ADR be scheduled to run at a specific time?

Yes, an ADR can be scheduled to run at a specific time, such as after Microsoft’s monthly patch release.

How to create a SCCM Automatic Deployment Rule

 ADR Creation

Creating the ADR is fairly easy process. Open your SCCM console and navigate to SOFTWARE LIBRARY, then expand SOFTWARE UPDATES. Now right click AUTOMATIC DEPLOYMENT RULES and choose CREATE AUTOMATIC DEPLOYMENT RULE.

SCCM Automatic Deployment Rule

ADR General TAB

Now give the rule a descriptive NAME that will easily identify what this ADR is for (ie Monthly Update deployment to Desktops), a DESCRIPTION, choose a TEMPLATE (I choose Patch Tuesday) and then the TARGET COLLECTION. Now you will need to choose between CREATE A NEW SOFTWARE UPDATE GROUP or to ADD TO AN EXISTING SOFTWARE UPDATE GROUP.  The differences between these two settings is, Add to an existing Software Update Group will create a new Software Update group the first time it runs, but then subsequent schedules of the ADR will utilise this update group, or creating a new software update group will create a new update group each time the ADR runs. Choose one of the options and then click on NEXT.

(Make sure you have the checkbox enabled, ENABLE THE DEPLOYMENT AFTER THIS RULE TO RUN).

SCCM ADR SETUP

ADR Deployment Settings TAB

We are now presented with the Deployment Settings page next. You can choose to use Wake On Lan (if you have that enabled in your environment) and what level of detail we want regarding the Patch Deployment. You can also specify to Automatically deploy all software updates found by this rule and approve any license agreements. Obviously this will automatically approve and licenses agreements that may be required to deploy the updates, a very handy feature. Once you are happy to proceed, click on NEXT.

SCCM ADR Deployment Settings

ADR Software Updates TAB

Next we get to choose the products and the severity among other things for the ADR. Choose the products you want (ie in this example Im choosing Windows 10) and the patch severity (Critical, Important, Low, Moderate or None) and date the patches were released (following on from my previous comments, I want the last months patch releases) . Click on NEXT when you have chosen the products you wish patches deploy to.

SCCM Software Updates

ADR Evaluation Schedule TAB

This tab allows you to configure the settings for when you would like the SCCM Automatic Deployment Rule to evaluate available software updates. You need to configure this schedule to run less frequently than your SUP synchronisation will run (highlighted in the example picture below). You can choose not to run this rule automatically (ie you will have to run this manually if required), after the SUP synchronisation happens (which is the default) or according to a schedule you specify.

SCCM EVALUATION SCHEDULE

ADR Deployment Schedule TAB

On the ADR deployment schedule TAB, we choose when we would like our updates to be deployed to our client machines. You can choose Universal Coordinated Time or Client machine local time, when you would like the updates to be available to clients, and the software installation deadline. Choose the last two settings carefully as the wrong choice will have a major impact on your environment and users if incorrect.

SCCM Deployment Schedule

ADR User Experience TAB

One of the most important TABS, is the User Experience TAB. Do you wish to notify the users that updates are available and have them install them prior to the deadline you have set? Would you like the machines to automatically install restart at the deadline? Do you want to suppress a restart on Desktops or Servers, or even both? Choose the required settings and then click NEXT.

SCCM User Experience

ADR Alerts TAB

The SCCM Automatic Deployment Rule alerts TAB is next. Various settings are available of how you would like to be alerted. From when the rule fails, to compliance settings to alert you of the percentage of machines that are compliant. Additionally, you can generate alerts to System Centre Operations Manager (or SCOM) if you have this in your environment. Again, choose your required settings and click on NEXT.

SCCM ADR Alerts tab

ADR Download Settings TAB

The ADR download settings tab will allow you to specify what and where the client machine downloads the updates from. Obviously, if they are connected to your corporate LAN, the nearest SCCM distribution point is the ideal location. Should the updates not be available on a preferred distribution point, then you can choose not to install updates, or from a fallback location. Allowing the client machines to share the update content with other clients on the same subnet is a great thing to have, especially if they do not have a local SCCM distribution point, or are on a slow WAN link. Additionally, you can allow those clients to download from Microsoft Update.

Click on NEXT when ready to proceed.

SCCM ADR Download Settings

ADR Deployment Package TAB

 We can now create a new deployment package, or select an existing one. I will create a new deployment package in this example to show you how that is done.

Choose CREATE A NEW DEPLOYMENT PACKAGE.

Give the deployment package a descriptive name, a description that is easy to identify, where you would like the source files to live (remember this should be a UNC path, so make sure to have shared out the folder and given the correct permissions for SCCM to save the updates to).

Click on NEXT when completed.

SCCM ADR Deployment Package

ADR Distribution Points TAB

Select the distribution points you wish the updates to be available from and for you client machines to download from. You can choose individual SCCM Distribution Points, or a Distribution Point Group. Click on NEXT when you have entered these details.

SCCM ADR Distribution Points

ADR Download Location TAB

Choose where to download the updates from. Should you have a location where updates are downloaded, you can specify that, or should you be using a Microsoft’s WSUS Server, to download them directly from the internet. Click on NEXT when done.

SCCM ADR Download Location

ADR Language Selection TAB

Now choose the appropriate languages you want the patches to download in and then click NEXT.

SCCM ADR Language Selection

ADR Summary TAB

We are almost there. Almost finished. At the SCCM Automatic Deployment Rule Summary TAB, review the choices you have made and make sure they are correct. When you are happy with the settings, click on NEXT to continue.

SCCM ADR Summary TAB

ADR Completion TAB

We made it. We finally got there. The Automatic Deployment Rule is now setup and will run with the settings you have specified. You can now close the wizard.

SCCM ADR Completion

If you followed this post and were careful with the settings you have chosen for your SCCM Automatic Deployment Rule, then the updates you have selected will now deploy to your client machines, when and how you have requested.

See how SnaPatch can help you with Patching your Virtual Server environment.
