How to Setup Azure Files

Feb 20 2023

Azure Files Overview

As businesses grow, so does the amount of data they accumulate. And as data grows, so does the need for a reliable, secure, and scalable storage solution. One such solution is Microsoft Azure Files. Azure Files is a cloud-based file storage solution that can be accessed from anywhere, on any device. In this article, we’ll walk you through how to set up Azure Files step-by-step.

What is Azure Files?

Azure Files is a cloud-based storage solution that allows businesses to store and access their files from anywhere, on any device. It is a fully managed service that eliminates the need for businesses to manage their own file servers. Azure Files provides businesses with a scalable, secure, and reliable storage solution that can be accessed over the internet or through a virtual private network (VPN).

Benefits of Azure Files

Azure Files is a fully managed cloud-based file share service provided by Microsoft Azure. It allows users to store and share files in the cloud, with support for the Server Message Block (SMB) protocol, which is commonly used by Windows file shares.

Azure Files provides a number of advantages for users, including:

Scalability: Azure Files can easily scale to meet the growing needs of users and organizations, allowing them to store and share files in the cloud without worrying about capacity limits.
Easy management: Azure Files is fully managed by Microsoft, so users don’t have to worry about maintaining their own file servers or managing the underlying infrastructure.
Accessibility: Azure Files supports the SMB protocol, making it easy for users to access and share files from any Windows-based device, including desktops, laptops, and servers.
Data protection: Azure Files provides built-in data protection and disaster recovery features, including geo-redundancy and automatic backups, to help ensure that users’ data is always available and secure.

Azure Files is often used by organizations that need to share files across multiple locations or teams, or that need to provide secure access to files for remote or mobile workers. It can also be used for backup and archiving purposes, and to support applications that require file share access.

How to setup Azure Files

Creating an Azure Files account

Before you can start using Azure Files, you’ll need to set up an Azure account. If you don’t already have an Azure account, you can sign up for a free trial.

Once you have an Azure account, you can follow these steps to set up Azure Files:

The first step in setting up Azure Files is to create an account. Follow these steps to create an account:

Go to the Azure portal and sign in to your account.
Click on the “Create a resource” button in the top left corner of the dashboard.
Search for “Azure Files” in the search bar and select it from the list of available services.
Click on the “Create” button to start the setup process.
Choose a subscription, resource group, and storage account for your Azure Files account.
Choose a location for your account and click on the “Review + create” button.
Review your settings and click on the “Create” button to create your account.

Creating a file share

The first step in setting up Azure Files is to create a file share. A file share is a container for your files. To create a file share, follow these steps:

Go to your Azure Files account and select the “File shares” option from the left-hand menu.
Click on the “New” button to create a new file share.
Enter a name for your file share and set the quota for the share.
Click on the “Create” button to create your file share.

Configuring security settings

Once you have created a file share, you can configure its properties to meet your specific needs. To configure the properties of an Azure file share, follow these steps:

Go to your file share and select the “Access control (IAM)” option from the left-hand menu.
Click on the “Add” button to add a new role assignment.
Select the role you want to assign to the user or group.
Enter the name or email address of the user or group you want to assign the role to.
Click on the “Save” button to save the changes.

Mapping a drive to Azure Files

You can map a drive to Azure Files to access your files as if they were stored on your local computer. Follow these steps to map a drive to Azure Files:

Go to your file share and select the “Connect” option from the top menu.
Select the “Windows” option to download the PowerShell script.
Open PowerShell as an administrator and run the downloaded script.
Enter the storage account name and the file share name when prompted.
Enter your storage account key when prompted.
The drive will be mapped to your computer.

Accessing Azure Files from the web

You can also access your Azure Files from the web. Follow these steps to access your Azure Files from the web:

Go to the Azure portal and sign in to your account.
Go to your Azure Files account and select the “File shares” option from the left-hand menu.
Click on the file share you want to access
Click on the “Connect” button and select the “Connect with file explorer” option.
Enter your Azure Files account credentials when prompted.
File Explorer will open, and you can access your files just as you would on your local computer.

Azure Files Best Practices

To get the most out of Azure Files, it’s important to follow best practices. Some best practices for using Azure Files include:

Using the appropriate access level for your file shares.
Setting up alerts for important events, such as exceeding your file share quota.
Monitoring your file shares regularly to ensure they are performing as expected.
Backing up your data regularly to protect against data loss.

Azure Files FAQ

Is Azure Files secure?

Yes, Azure Files offers several security features, such as access control and encryption, to ensure that your files are secure.

Can I access my Azure Files from anywhere?

Yes, you can access your Azure Files from anywhere with an internet connection.

How much does Azure Files cost?

Azure Files pricing is based on the amount of storage and data transfer you use. You can check the current pricing on the Azure website.

Can I share my Azure Files with others?

Yes, you can share your Azure Files with others by assigning them appropriate permissions.

What security measures are in place to protect my data stored in Azure Files?

Azure Files use a variety of security features, such as role-based access control (RBAC), Azure Active Directory (AAD) authentication, and encryption at rest. Microsoft also offers various compliance certifications for Azure services, including Azure Files, to meet different regulatory requirements.

Can I use Azure Files for backup and disaster recovery?

Yes, you can use Azure Files for backup and disaster recovery by setting up regular backups of your file shares and replicating them to another region or data center. Azure also offers other backup and disaster recovery solutions, such as Azure Backup and Azure Site Recovery, that can be used in combination with Azure Files to provide a comprehensive data protection strategy.

Azure Files Final Thoughts

In conclusion, as your organization’s storage needs grow, it can be challenging to keep track of where your Azure storage is being consumed, leading to unnecessary costs. However, with Cloud Storage Manager, you can easily monitor and manage your Azure Files and Blob Storage, which will help you take back control and reduce costs.

With features like the Azure Storage Tree view and Reports, you can quickly identify which files are taking up the most space and move them to lower storage tiers. You can also utilize Azure Blob Search to find specific files and gain insights into the growth and tiering of your storage accounts.

In addition, Cloud Storage Manager provides a comprehensive overview of your Azure Files consumption, allowing you to quickly identify areas for improvement and optimize your storage usage. With Cloud Storage Manager, you can stay on top of your Azure Files and keep your costs under control.
